- The apparatus consist of a rigid frame that supports two conical hoppers vertically aligned above each other and mounted above a cylinder.
- The top hopper is slightly larger than the bottom hopper, while the cylinder is smaller in volume than both hoppers.
- To perform the test, the top hopper is filled with concrete but not compacted.
- The door on the bottom of the top hopper is opened and the concrete is allowed to drop into the lower hopper.
- Once all of the concrete has fallen from the top hopper, the door on the lower hopper is opened to allow the concrete to fall to the bottom cylinder.
- The excess concrete is carefully struck off the top of the cylinder and the mass of the concrete in the cylinder is recorded.
- This mass is compared to the mass of fully compacted concrete in the same cylinder achieved with hand Roding or vibration.
- Complete with trowel and tamping bar 0-60 cms long X 16mm dia.
- Concrete Scoop
- Straight Edge
- Weighing Balance
