Home Shop COMPRESSION TESTING MACHINE – HAND OPERATED PILLAR TYPE

COMPRESSION TESTING MACHINE – HAND OPERATED PILLAR TYPE

Compression Testing Machine – Hand Operated Pillar Type: MTCT-106A

This machine is quite useful on field Laboratories or mobile testing laboratories or Vans which frequently change site or location. It is particularly useful where constant and consistent Electric power is not available. The load is applied manually and observed on a Pressure gauge. The Pressure Gauge has maximum load indicator which stand still even after the specimen under test crushes and has to be set to zero manually.

FEATURES:-

High Stability
Self-aligning platen assembly.
Gauges are calibrated in Kilo Newton against certified Proving Ring.
Suitable for testing cubes of various sizes
Using special platens, bricks also can be tested.
Hard chrome plated piston with new type of long life oil seal.
Four Pillar Model – superior in design, reliability and accuracy
Practically no welded parts, all joints reinforced with heavy nut/bolt to withstand occasional over loading and to ensure center loading.
Rounded Corners – add to elegance and safeguard against injury
Hardened and grinded platens with guide lines for placing sample for Testing

Category: Concrete Testing Equipment

Description
Product Enquiry

Description

OPTIONAL ACCESSORIES:-

Spare Oil Seal
Brick Testing Attachment
Hydraulic Oil (Tin of 5 Liters)

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
