Description
Technical Specification:-
- The apparatus consists of a panel for wall mounting on which are fitted -1.0 to 20 kg/cm2 x 0.1 kg/cm2 a pressure gauge, Bourdon tube type 20 cm dia.
- Manometer glass U-tube manometer for measuring low positive pore pressures negative pore pressures and checking zero error of pressure gauge.
- It is provided with a mercury trap (Mercury supplied at extra cost).
- Null indicator made out of clear transparent Perspex with mercury trap and cursor to indicate the mercury level.
- Burette 50 ml Burette for measuring the volume change in the soil specimen.
- Pressure pump fitted with four sleeve packed valves.
- Operated by mean of a hand wheel on the end of the piston rod which is threaded through the pump cap and gives a smooth, fine adjustment of pressure
- Copper coil and water reservoir
- The unit is tested against leaks upto 10 kg/cm.sq.
