Description
Technical Specification:-
- Hopper capacity 550 litter
- Batch capacity 450 litters
- Machine output/Hrs 10 cu.M/hr
- Power 10 HP 3 phase Eel.motor
- Water tank capacity 1000 liters
- Weighing system Load cell based weighting system with digital display batch controller
- Hydraulic pump 20 gear pump@ 180 bar
- Gear ring and roller accurately machined with gear cutting operation supported by heavy duty twin rollers guide
- Wheels pneumatic wheels (4 nos.) 600 x 16
- jack leveling pin
Accessories:-
- Chemical additive system
- Belt conveyor for aggregate and sand loading
- Cement silo
- Conveyer belt for transit mixer loading
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
