WEIGH BATCHER

Weigh Batcher: MTCE-02

Weigh Batching is a process of measuring concrete ingredients which are considered a correct and preferred method as it gives a uniform proportion. The measure of weigh batching takes place in a very important modernized concrete batching and mixing plants. It is a flexible, simple, and accurate system. There are different types of weigh batches which are available as per the requirements at the construction sites.

There are three types of Batchers:-

Manual: This system is used for small jobs where the weigh batching of concrete ingredients are done manually.
Semi-automatic: In this system, the bin gates are manually opened by operated switched and automatically gets closed when the material is delivered.
Fully automatic: With an automatic microprocessor, it controls the batching arrangements. It not only batches the correct proportion of the mixer but also the moisture content is automatically detected which leads to the correction in order to have the desired consistency.

Features:-

Contains two buckets for gravel and sand.
Sturdy construction
Easy to install
Low maintenance cost
Dimensionally accurate
High efficiency rate
Material can be unloaded directly into 10/7 mixer hopper.
This construction machine has Controlled Operation, Low Coefficient of Friction and Wear of Machines.
The Dust-Free Plant Environment is Exemplifies the Fabrication and Arrangement of Parts.
It is well known for its Thermal Conductivity.
Joints provided with dust covered bearings.

Description

Technical Specification:-

Capacity 2 Bins suitable for 10/7 cuft concrete mixer.
Chassis Heavy Duty Chassis of 75 x 40 mm channel
Wheels Metal Wheels – 4 no’s
Excellent concrete output
High Accuracy
Weigh Batcher Scale Type
Hoppers double Hoppers from 3.15mm thickness plates.
Designed to adjust with old concrete mixer
Heavy duty robust made out of heavy steel section.
Transmission by mechanical joints provided with dust covered bearings.
Weighing Pan weight of 50 and 100 kg and jockey weight to adjust
System the weight from 0 kg to 50 kg’s

Accessories:-

Cement filter
Safety valve
Level indicator
Broken arch
Butterfly valve
Guard rail
Waterproof
Moisture proof
Small footprint

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
