Description
Technical Specification:-
- Display The decimal display point is positioned by the channel selector switch.
- Power-220 V ± 10% mains, 50 Hz, single Ph. AC supply.
- No. of channels 3
- Parameter display By a selector switch.
- Load Cell – 1 No.
- Capacity 2 KN (200 kgf) Universal type, TCPR
- Max. Overload 110% of the rated capacity
- Sensing Element Strain Gauges in full bridge configuration. Displacement Sensor – 2 Nos.
- Range ± 19.99 mm
- Sensing Element : LVDT
- The specimen is exposed to a constant load while an increasing horizontal force is applied to one of the sections of the shear box.
- Area of soil sample 30 cm2
- Lever ratio 1:12
- Vertical loading 50, 100, 200, 300, 400 KPa
- Horizontal loading 1.2 KN
- Shear rate 5, 2.4, 1.5, 1, 0.8, 0.02, 0.01 mm/min
- Specimen size 30cm2
- The working table is made of Stainless steel
- Pushing mechanism Stepping Motor
- High Precision & Low Noise
- Speed Variable
- Display system LCD / LED
- Power Supply 220 ~ 240 V AC, 50~60 Hz
- This force causes a shear failure along the moment between the box sections of this.
- The shear force and the normal load are measured directly.
- The rate of strain is attuned by the quickness of the horizontal force applied.
- The load yoke in these direct shear test apparatus helps in balancing the loading system.
- Capacity: 8 kg/sq.cm
