THREE TO SIX PHASE CONVERSION TRAINER
Three to Six Phase Conversion Trainer: MTEE-44
Three to Six Phase Conversion Demonstrators a comprehensive training product used to illustrate the core concepts of Electrical Engineering. With this product, user can learn of how Three Phase Supply can be converted into Six Phase with proper phase shift by using three Single Phase Transformers.
Separate terminals are provided to analyze Six Phase waveform using Single Phase as a reference waveform. The product familiarizes with the phenomenon of Polarity usually expressed as a round dot. User can also get to know the significance of Three Phase Parameters and verify the Star and Delta connection properties.
FEATURES:-
- Separate terminals to analysis waveforms
- Control board consist of high grade FRP material to provide utmost safety to the users
- Three Identical Single Phase Transformer
- Equipped with supply indication lamps
- Provided with bulb holder to use suitable load
- Designed by considering all the safety standards
- Diagrammatic representation for the ease of connections
- Exclusive and Attractive Design.
TECHNICAL SPECIFICATIONS:-
- Mains Supply : Three Phase, 415V ±10%, 50Hz
- Transformers Specification (3 nos.)
- Primary Winding : 0 – 230V
- Secondary Winding : 30 – 0 – 30V
- Digital Meters Used
- AC Voltmeter : 450V
- AC Ammeter : 5A
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
