THREE PHASE TRANSFORMER LAB
Three Phase Transformer Lab: MTEE-14
Three Phase Transformer labs is an adaptable training system for the Electrical laboratories. The product helps understand basic concepts and functioning of a Three Phase Transformer.
The product is represented in an easy way so that each test can be studied differently in proper sequence.
Three Phase configurations such as Star-Star, Star-Delta, Delta-Star and Delta-Delta, Measurement of different losses and consequently determine efficiency and voltage regulation at any predetermined load etc.
FEATURES:-
- Stand-alone operation
- Graphical LCD display for high resolution
- Flexibility to use in star and delta configuration
- Equipped with Supply Indication Lamps
- Facility to display entire parameter in single shot
- Designed by Considering All the Safety Standards
- Diagrammatic Representation for the Ease of Connections
TECHNICAL SPECIFICATIONS:-
- Mains Supply : 415V ±10%, 50Hz
- Type : Three Phase
- Power Rating : 1kVA
- Primary Voltage : 415V
- Secondary Voltage : 230V
- Rated Current : 4A
- Graphical LCD display : 240 x 125 Pixel
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
