HOPKINSON`S TEST OF DC MACHINE
Hopkinson’s Test of DC Machine: MTEE-22
Hopkinson’s Test of DC Machine is an adaptable training system used for Electrical Laboratory. It is designed to demonstrate the fundamental concepts and also facilitates easy learning about the various losses of DC Machine.
Two similar machines are required to carry out Hopkinson’s Test.
Electrically these two machines are connected in parallel to determine the Efficiency of DC Machine by separately calculating the losses
Separate terminals of Armature and Field windings are brought out on a terminal box fitted on top of the motor.
The training system includes terminals for Rheostat and Starters so that these devices can be connected externally to the panel has been designed in such an easy way that users can observe the voltages and current of windings of both the motors. All protection devices are in built negligible chance of fault or danger
FEATURES:-
- Electrical Loading Arrangement
- Flexible Shaft Coupling Arrangement
- Control board consist of high grade FRP material to provide utmost safety to the users
- Provided with Digital Tachometer
- Machine with Class “B” Insulation
- Heavy Duty Base/Channel
- Terminals provided to use the optional externally
- Designed by considering all the safety standards
- Diagrammatic representation for the ease of connections
TECHNICAL SPECIFICATIONS:-
- DC Machines (2 Nos.)
- Type : Shunt
- Rating : 1 HP
- Voltage Rating : 220V ± 10%
- Speed : 1500 RPM ± 7.5%
- Digital Meters used
- DC Voltmeter : 300V
- DC Ammeter: 5A (4 nos.)
- Digital Tachometer : 20,000 RPM
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
