SWINBURN`S TEST OF DC MACHINE
Swinburn’s Test of DC Machine: MTEE-21
SWINBURN’S Test of DC Machine is an important training system for Electrical Laboratories. It can be aptly employed for understanding the fundamental concepts and functioning of DC Motor. SWINBURN’S Test is the method through which losses are measured separately and efficiency at any desired load can be predetermined.
Separate terminals of armature and field windings brought out on a terminal box fitted on top of the Motor. The training system includes terminals for Rheostat and Starter so that devices can be connected externally to the panel. The product thus provides explicit understanding of the subject.
FEATURES:-
- Machine with Mechanical Loading Arrangement
- Provided with Digital Tachometer
- Machine with Class “B” Insulation
- Control board consist of high grade FRP material to provide utmost safety to the users
- Heavy Duty Base/Channel
- Brake-Drum/Pulley with heat suppression facility
- Equipped with supply indication lamps
- Designed by considering all the safety standards
- Diagrammatic representation for the ease of connections
TECHNICAL SPECIFICATIONS:-
- DC Machine
- Type : DC Shunt
- Power Rating : 1HP
- Voltage Rating : 220V, ±10%
- Speed : 1500 rpm ±5%
- Loading Arrangement: Mechanical
- Digital Meters
- DC Voltmeter : 300V
- DC Ammeter: 5A (2 nos.)
- Digital Tachometer : 20,000 rpm
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
