POWER MEASUREMENT BY THREE VOLTMETER & THREE AMMETER METHOD
Power Measurement by three Voltmeter & three Ammeter Method: MTEE-49
Power Measurement by Three Voltmeter and Three Ammeter Method is an exclusive and important product designed to explain students about the basic concepts of power measurement in electrical devices by Three Voltmeter and Three Ammeter Method. Using these method students can calculate the power and power factor in case of non-availability of the Wattmeter. This is a user friendly product in which students can make connections and calculate the power by using test points provided. The panel is equipped with all necessary protection circuits to avoid fault.
FEATURES:-
- Digital Panel Meters for better accuracy
- Inbuilt Inductive load
- Equipped with Supply Indication Lamps
- Designed by considering all the safety standards
- Diagrammatic representation for the ease of connections.
TECHNICAL SPECIFICATIONS:-
- Mains supply : 230V±10%, 50Hz
- Auxiliary supply : 230V±10%, 50Hz
- Choke Coil : 300mH, 5A
- Voltmeter: 0-500V (3 Nos.)
- Ammeter: 0-5A (3 Nos.)
- Single Phase: 0-230V, 5A
- Rheostat : 45Ω, 5A
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
