INDUCTION MOTOR COMPOUND GENERATOR LAB
Induction Motor Compound Generator Lab: MTEE-33
Induction Motor Compound Generator Lab is an adaptive training system for Electrical laboratories. It is designed to demonstrate the fundamental concepts of DC Compound Generator on different loading conditions.
The diagrammatic representation is provided on the control panel so that students can make connections themselves. All protection circuits are inbuilt, so there is very less chance of fault or danger.
FEATURES:-
- Electrical loading arrangement
- Flexible shaft coupling arrangement
- Provided with Digital Tachometer
- Machine with Class “B” Insulation
- Heavy Duty Base/Channel
- Equipped with Supply indication lamps
- Designed by considering all the safety standards
- Diagrammatic representation for the ease of connections
- Exclusive and Compact Design
TECHNICAL SPECIFICATIONS:-
- Three Phase Induction Motor
- Type : Squirrel Cage
- Rating : 2 HP
- Voltage Rating : 415V AC ±10%
- Speed : 1440 RPM ±5%
- Insulation : Class ‘B’
- DC Machine
- Type : Compound
- Rating : 1HP
- Speed : 1500 RPM ±7.5%
- Insulation : Class ‘B’
- Digital Meters used
- DC Voltmeter: 300V (2 nos.)
- DC Ammeter: 5A (2 nos.)
- AC Voltmeter : 450V
- AC Ammeter : 5A
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
