Sieve Shaker Electromagnetic

Sieve Shaker Electromagnetic: MTAT-04

This Sieve Shaker uses electromagnetic impulses to impart a triple vibrating action.

Vertical
Lateral
Rotational

The shaker is of a simple and sturdy construction making it ideal for continuous and intense use. It is operated and controlled via a separate control panel enabling high precision, performance and repeatability. It is fitted with a digital 1 to 999 minute timer, accessed through the digital control panel. This separate panel also gives the user control of the vibration intensity and pauses between sieving actions, which is particularly useful when sieving fine materials.

Note:-Wet sieving kits in the appropriate sizes may be used with this shaker.

Features:-

Tri-dimensional sifting motion
2 modes of sifting
Low maintenance
Isolation of vibrations from work surface
Particle size analysis
Programmable amplitude
Programmable sieving duration
Larger LCD
Low noise
Programmable shake time from 1 min to 99 mints
Ideal for particle size analysis and separation
Intermittent and continuous shifting motion with 15 program amplitude
Suitable for dry and wet sieving

Description

Technical Specification:-

Digital control panel functions 1-999 minute test timer vibration intensity pause time.
RATING 450/750W
power supply (220-240V50/60Hz1PH)
Dry sieving Standard
Mode of operation Continuous and intermittent
Intermittent operation At intervals
Dry sieving standard
Inter mitten operation At internals (0.5 sec)
Capacity (up to 8 sieves of 50 mm height) (up to 16 sieves of 25 mm to 4 mm)
Shake time programmable from 1 min to 99 min
Power level programmable from 5 to 20
Display 16×2 character alphanumeric LCD
Noise level (less than 61 db without sieves at maximum amplitude) (less than 71 db with sieves and material at maximum
Power level 220/230V AC,50 HZ,600VA

Accessories:-

Backlight knob fit locking arm
Test sieve.
Vertical rod
Rod (Qty.2)
Clamp (Qty.1)

Note: – Optional Accessories may be used with this

Wet sieve attachment
Particle size analyzer software

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK “keeps the right to modify the content in the product without prior notice
