TOUCH BIO CHEMISTRY ANALYZER
TOUCH BIO CHEMISTRY ANALYZER : EM-246
| Human Machine Interface | TOUCH PANEL/KEYPAD |
| Linear Measurement Range | 0.000 to 3.000 Absorbance Unit (A) |
| Photometric Accuracy | ±2% or 0.007 whichever is higher, from 0 to 1.5A, ± 3% from 1.5A to 3.0 A. |
| Filters | |
| Type of Filter | High Quality, Narrow band interface |
| Wave Length | 340, 405, 510, 546, 578 and 630 mm & two Optional flow cell. |
| Dry Block Incubator | 15 positions at 37 C. |
| Temp. of Cuvette/Flow Cell Block | 25 C, 30 C and 37 C by Peltier effect. |
| Light Source | Tungsten Halogen |
| Display | 5″ Graphics LCED, Nagative Blue, STN |
| Printer | Built in Thermal Printer, 20 Column |
| Storage Capacity | Open tests with 30 QC results/test & 2500 Patient results. |
| Analysis Mode | Absorbance End point Fixed Time Kinetic Differential Ratio Coagulation |
| Power | 50 Watts / 115-230 Volts ± 10%, 60-50 Hz |
Features
Direct access to Test by Touch of key
Sophisticate software for kinetic graph with built in delta calculation for saturated (high) samples from graphic display without diluting and rerunning the samples.
Reliable peristaltic pump with maintenance free operations.
Unique circuitry for long lamp life.
Triple cuvette system.
Robust system with built in stabilizer.
Monochromatic, Bichromatic Measurement.
Levy Jennings and standard deviation graphs.
Editing of saved tests.
Patient report with PID & Name.
USB Interface
