ELISA WASHWELL PLATE ANALYZER
ELISA WASHWELL PLATE ANALYZER : EM-313
Features
Specially designed Manifold assembly to prevent any scratching on bottom of well.
User programmable soak time, wash cycles and dispensing volume.
On Board two plate incubator at 370C with programmable timer.
Waste bottle full warning with audible alarm.
Built-in stabilizer.
Continuous aspiration to prevent overflow.
Removable manifold.
Ability to wash single strip of 8 wells.
Auto detection of bottom of well and collision prevention.
Washwell PLATE
Technical Specifications
| Manifold | 8 Way Manifold |
| Dispensing | |
| Method | Specially designed Peristaltic Pump |
| Volume | 300 to 400 ml in steps of 50 ml |
| Aspirating | |
| Method | Continuous through diaphragm pump while Dispensing hence preventing overflow. |
| Residual Volume | < 5 ml |
| Waste Bottle | One (Capacity 2 litres) with audible alarm when bottle is completely filled in with waste solution |
| Wash Bottle | One (Capacity 2 litres) |
| Rinse Bottle | One (Capacity 2 litres) |
| Display | Single line Backlit LCD with 16 characters |
| Liquid contact materials | Silicon, Stainless steel, derline |
| Memory | 8 KB Non volatile RAM battery back up supporting 35 open Channels |
| Washing Method | Longwash, shortwash Rinsing, Priming |
| Incubator | For Two ELISA Plates, 37º C |
| Timer | Individually Programmable |
| Power | |
| Wattage | 50 Watts |
| Voltage | 115 – 230 Volts ± 100%, 50 /60 Hz. |
| Operating Position | On horizontal, rigid, flat and vibration free surface |
| Operating Conditions | |
| Temperature | + 18º C to 35º C |
| Humidity | up to 85 % |
| Storage Conditions | |
| Temperature | – 10º C to 60º C |
| Humidity | up to 85 % |
| Enclosure | ABS Fire retardant |
