COMPACT BIOCHEMISTRY ANALYZER
COMPACT BIOCHEMISTRY ANALYZER : EM-245
Technical Specifications :
Human Machine Interface
Dynamic keypad
Linear Measurement Range
0.000 to 3.000 Absorbance Units (A)
Photometric Accuracy
2% or 0.007 whichever is higher, from 0 to 1.5 A,
3% from 1.5 A to 3.0 A
Filters
High Quality Narrow band Interference
340, 405, 510, 546, 578 and 630 mm & Two Optianal
Flow cell
18 l & up to 1000 l Sipping volume
Temp. of Cuvette / Flow cell Block
25 C, 30 C and 37 C by Peltier effect
Light Source
Tungsten Halogen
Display
Graphics LCD
Printer
Built in Thermal Printer, 20 Column
Storage Capacity
250 User Defined Test Programs & 2500 Patient results
Analysis Mode
Absorbance, End Point, Fixed Time, Kinetic, Defferential, Ratio, Coagulation
Voltage
115 – 230 Volts ± 10%, 50 – 60 Hz
Power – 100 VA
Features
52 Direct Access Test Keys
Specially designed long life Perisaltic Pump
Unique circuitry for long lamp life
Triple cuvette system
Monochromatic, Bichromatic measurement.
Patient report with PID & Name
User friendly software USB Interface
