EXPERIMENTATION WITH CHARACTERISTICS OF TTL AND CMOS

Experimentation with Characteristics of TTL and CMOS: MTBE-39

Experimentation with Characteristics of TTL and CMOS is a compact product designed to explain the fundamentals of Transistor–Transistor Logic (i.e. TTL) and Complementary Metal Oxide Semiconductor (i.e. CMOS), like Voltage Transfer Characteristics, Noise Margin and Gate Delay. Inbuilt Function Generator and DC supply is provided for ease of operation. The Voltage Transfer Characteristic of a logic gate is a graph between gate output voltage and gate input voltage. Noise margin is the voltage difference by which the signal exceeds the threshold voltage for Logic Low or Logic High. Gate delay is the span of time starting from the instant when the input to a logic gate becomes stable, to the time that the output of that logic gate becomes stable.

FEATURES:-

In-built variable DC power supply
In-built Function generator
Illustration of both TTL and CMOS ICs

Description

SCOPE OF LEARNING:-

To study the voltage transfer characteristics, noise margin and gate propagation delay of TTL NAND gate
To study the voltage transfer characteristics and gate propagation delay of TTL Schmitt trigger NAND gate
To study the voltage transfer characteristics, noise margin and gate propagation delay of TTL NOT gate
To study the voltage transfer characteristics and gate propagation delay of TTL Schmitt Trigger NOT gate
To study the voltage transfer characteristics, noise margin and gate propagation delay of CMOS NAND gate
To study the voltage transfer characteristics and gate propagation delay of CMOS Schmitt trigger NAND gate
To study the voltage transfer characteristics, noise margin and gate propagation delay of CMOS NOT gate
To study the voltage transfer characteristics and gate propagation delayof CMOS Schmitt Trigger NOT gate Scope of

TECHNICAL SPECIFICATIONS:-

DC power supply : +12V, +5V
Variable
DC power supply : 0 to +12V
0 to +5V
Pulse Generator
Frequency : 100kHz ±15%
Amplitude : 5V
Mains Power supply : 230V AC ±10%, 50Hz

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
