EXPERIMENTATION WITH DIODES

Experimentation With Diodes: MTBE-17

The diode is a device formed from a junction of n-type and p-type semiconductor material. The lead connected to the p-type material is called the anode and the lead connected to the n-type material is the cathode. In general, the cathode of a diode is marked by a solid line on the diode. The primary function of the diode is rectification. When it is forward biased (the higher potential is connected to the anode lead), it will pass current. When it is reversed biased (the higher potential is connected to the cathode lead), current flow is blocked.

FEATURES:-

A complete system to study the diode characteristics
Forward and reverse characteristics experiment can be performed on this trainer kit
Silicon, Zener and Light Emitting Diode (LED) are provided with this system
Inbuilt Ammeter and Voltmeter are provided
Digital display for displaying voltage and current
Different test points are provided
Online product tutorial
A diode
A DC voltage supplier
Bread board
100Ω resistor
2 multimeter for measuring current and voltage
Connecting wires

Category: Basic Electronics

Description
Product Enquiry

Description

SCOPE OF LEARNING:-

Study of V-I characteristics of Silicon Diode
Study of V-I characteristics of Zener Diode
Study of V-I characteristics of Light Emitting Diode (LED)
The diode should not be short-circuited.
That will allow a flow of huge current which might destroy the diode.
Current must not pass through it for a very long time.
It will then increase the depletion region and develop a fluctuating resistance.

TECHNICAL SPECIFICATIONS:-

On Board DC power supply: +12V DC
Ammeter
Range : 1µA to 200mA
Display : 3½ digit
Voltmeter
Range : 1mV to 200V
Display : 3½ digit
Mains power : 230V AC ±10%

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
