Description
FEATURES:-
- Built on firs principle of hydraulic s used for precision calibrator for pressure gauges and other sensing, trashing and recording pressure instrument.
- Bench mounted indigenous unit, simple to operate.
TECHNICAL SPECIFICATIONS:-
- Precision machined piston and cylinder with leveling screws
- Bourdon gauge with inlet and outlet valves Set of weights
- Educational software available as an option
- Pressure gauge: Bourdon tube range 0 to 200 KN/m2 (KPa)
- Area of piston: 244.8 x 10-6 m2
- Mass of piston: 0.5kg
- Ancillary masses: 2 x 0.5 kg, 1.0 kg and 2.5 kg
** Note: The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
