LARGE ANGLE STABILITY SYSTEM
Large Angle Stability System: MTFM-39
Large Angle Stability System is designed for the study of ship hydro statics and stability. A comprehensive manual provides hydro static stability and other data for ship models and includes a number of experiments which are useful to students. Exercises are conducted on a 1/70 scale model of a general cargo vessel of 28,000-tonne ship mass. Rolling, righting and the effects of flooding various compartments may be studied.
DEMONSTRATION CAPABILITIES:-
- Inclining experiment
- Influence of a free surface
- Influence of a suspended mass
- Effect of flooding various compartments
- Rolling experiments
TECHNICAL SPECIFICATIONS:-
- Apparatus designed to enable students to study ship hydrostatics and stability Supply includes a water tank, a floating ship model, a dynamo meter and a clinometers
- The model supplied is a 1/70 scale model of a 28,000-tonne general cargo vessel
- It includes a number of transverse watertight bulkheads in representative positions
- The compartments are fitted with individual flooding valves
- The model is constructed of glass reinforced plastic (GRP)
- Models of other ships are available as optional accessories
- The dynamo meter measures the righting moment of the model
- It holds the model at any angle of heel within the range, with the model either free to trim or with heeling axis kept horizontal
- It exerts no vertical force on the model
- It is floor standing, with castors and is supplied complete with counterweights
- Battery powered clinometers measures the inclination of the model, over the range of 0-45 degrees
** Note: The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
