LARGE ANIMAL INCINERATORS : JKA-230LA

Large Animal waste incinerators incinerate big dead animals like Cow, Buffalos, Oxe, Horse etc. It is widely used to destroy to animal infection diseases, viruses and animal waste material.
These products are manufactured using latest technology machinery.
Large Animal Incinerator is double wall construction, duly insulated with high efficiency ceramic bricks, with dual chambers for complete combustible their dead bodies/carcass. The burners of this system are fully automatic & efficient. The chamber temperature is controlled by a PLC digital
temperature controller. These products have separate doors for waste burning chamber and for ash collecting tray.

Achimney is provided for emission of fumes. The incinerator reduces most combustible solid waste to nearly 2-3 percent by volume and upto 3% by weight.

Large animal incinerator are easy to install and extremely durable equipment. It is available in varied capacity/sizes based on the requirement of Forest Department, Animal Industries and Veterinary Hospitals.

OPERATING PRINCIPAL :

The disposal of waste is based on the principal of incineration of the waste so as to destroy any degradable and infectious material and reduce it volume and mass without producing any type of pollution.

DESIGN:

The design is based on the guidelines set by Central Pollution Control Board (CPCB)-India and normally adopted by military installation all over the country and worldwide. The Efficient power is supplied by electricity as well as oil burners for larger installation.

FEATURES :

• Application : For Large Animals
• Model Type : Floor-standing
• Manual-Conveyor Belt (Optional)
• Temperature range: Min. 850 °C , Max. 1450 °C
• Power Requirement: Diesel, Electrical
• Temperature Monitoring : Provided
• Average ash residue (%) : 2-3%
• Design and prepare the dead animal incinerator with chamber (Primary and Secondary chambers) for complete combustion as per CPCB Norms.
• Filtration of smoke before releasing it in atmosphere.

GENERAL CONSTRUCTION :

• Robust, Reliable and Efficient
• Pre-fabricated 8 and 10mm robust mild steel casing, seam welded & suitably stiffened/braced where necessary
• Paint finishing – The Mild steel structures are completely painted using a two pack high grade paint system that is baked into the steel structure at 70° C for 10 hrs.
• The layers of refractory lining in the primary and secondary chambers totaling of 230 mm. rated at 1450° C, provide increased fuel efficiency.
• Counter weight resilient refractory fiber insulation lid, Gives excellent thermal efficiency.
• Removable roof and back plate for ease of maintenance.
• All combustion fuel pipe work and electrical systems are weather proof and in accordance.
• Excess air and rapid cooling systems fitted as standard, aiding cleaner burns and faster cool down times.

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement.
