POST PAID METERS
POST PAID Water METERS
CODE:MTPI-12
TECHNICAL SPECIFICATIONS
- Altitude : 1 000 – 1 250m above sea level
- Maximum Temperature : 50° C
- Size DN 15 and 20 Minimum permissible startingflow rate (l/h) 5 and 8 respectively
- The meters suitable for working pressures of up to 16 bar.
- The main casings of copper alloy containing not less than 63 percent copper i.e. they brass of good quality.
- The registers have a single straight row of easily readable digits indicating the consumption in m³ with an indicating range of at least 99999 m³. The registers also indicate the consumption in liters to the nearest litre, either by means of digits of a different colour to the digits that indicate the consumption in m³ or by means pointers rotating over appropriately calibrated circular dials.
- All meters have integral check valves installed in the outlet ends of the meters. .
The following marked on the dial:
- Type of meter
- Normal or Permanent flowrate (Qn or Q3) in m³/h
- Metrological Class or R-Rate
- Pressure class
- Temperature class
- Symbol of manufacturer
- Patent approval number
- Year of manufacture
- LWB
CERTIFICATION: ISO 4422-1:1996, 1183-1:2019, 527-1:2019, EN 13959:2004, BS 6730, BS 21:1985
