UNDERSTANDING CALIBRATION OF ENERGY METER
Understanding Calibration of Energy Meter : MTEE-31
Understanding Calibration of Energy Meter is designed to deliver the practical knowledge of measurement of electricity consumption in real world. Today electricity is a vital element for human society.
The rapid growth in electric appliance usage has contributed to an explosive growth in electrification around the world. To use electricity better, it is required to have a deep knowledge of Electricity measurements provides in depth knowledge of Energy meter measurements and its calibration using Voltmeter, Ammeter and Watt meter.
It has two displays, one is Standard meter and another is Energy meter. The onboard LCD display works as Standard meter for calibration of Energy meter and display value of Voltage, Current and Watt. The Energy meter display provides energy consumption details. The facility to connect external Watt meter or Voltmeter and Ammeter is also provided.
FEATURES:-
- Single phase kWh Energy meter
- Inbuilt Voltmeter, Ammeter, Watt meter as Standard meter for calibration of Energy meter
- Big font LCD (16 x 2) for use as Standard meter/Energy meter calibration
- Separate Seven Segment Display as Energy meter
- Digital Calibration/ Operation using Keypad
- Sockets are provided to Connect External Voltmeter, Ammeter and Watt meter for Calibration
- Default and User Calibration modes are provided to avoid errors during Operation
- 5 LED Operation Indicators
- Learning material CD
TECHNICAL SPECIFICATIONS:-
- Auxiliary Power Supply : 90 – 270V ±10%, 50HzStandard meter
- Voltmeter Minimum/Maximum : 10/300V
- Ammeter Minimum /Maximum : 0.1/5A
- Watt meter Minimum/Maximum : 10/1500W
- Energy meter Display Resolution : 0.001kWh
- Frequency : 50Hz
- Fuse: 250mA (2 Nos.)
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
