PARALLEL OPERATION OF TWO SINGLE PHASE TRANSFORMER
Parallel Operation of Two Single Phase Transformer: MTEE-40
Parallel Operation of Two Single Phase Transformer has been exclusively designed to demonstrate the fundamental concepts of parallel connections of two or more single phase transformers.
One can load the transformer more than the rating of the individual transformer to analyze Parallel operation phenomenon. Students can learn about the significance of connecting the two transformers in parallel and its effect on the system. Additionally, one can also learn the polarity in the transformers.
The training system helps to get fully acquainted with the functioning of a single phase transformer. The varied scope of learning makes the subject easy and interesting.
FEATURES:-
- Two Identical Single Phase Transformer
- Facility to use Fixed and Variable Load
- Control board consist of high grade FRP material to provide utmost safety to the users
- Equipped with supply indication lamp
- Designed by considering all the safety standards
- Diagrammatic representation for the ease of connections
- Exclusive and Compact Design
TECHNICAL SPECIFICATIONS:-
- Mains supply : Single Phase, 230V±10%, 50Hz
- Single Phase Transformer (2 nos.)
- Rating : 1kVA
- Primary Voltage : 0-230V
- Secondary Voltage : 0-200-230V
- Rated Current : 4A
- Digital Meters Used
- AC Voltmeter: 450V (2 nos.)
- AC Ammeter: 10A (2 nos.)
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
