SOP & POS IMPLEMENTATION TRAINER
SOP & POS Implementation Trainer: MTBE-52
SOP & POS Implementation Trainer is a compact, ready to use digital electronics experiment board. It is useful for students to get a practical insight into the implementation of different canonical forms. The various applications of canonical forms are representing any Boolean function as a product of sum or sum of product. SOP & POS implementation trainer has built in clock source, logic high-low input facility and LEDs for visual indication of input-output states. Besides this, a +5V DC adaptor is also provided for power supply.
FEATURES:-
- Stand-alone system
- Easy illustration of different types of canonical forms
- LEDs for visual indication of input and output logic states
- SPDT switches for input logic selection
SCOPE OF LEARNING:-
- Study of Boolean function in different canonical forms
- Study of Quince Musky method and realize its NOR-OR
- Implementation
TECHNICAL SPECIFICATIONS:-
- DC Power Supply : +5V DC
- Logic levels
- +5V : High (Logic 1)
- 0V : Low (Logic 0)
- LED Indication : LED will be ON for logic high or ‘1’ state and will be OFF for logic low or ‘0’state.
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
