EXPERIMENTATION WITH ASTABLE AND MONOSTABLE MULTIVIBRATOR
Experimentation With Astable and Monostable Multivibrator: MTBE-23
Experimentation with As table and Mon stable Multivibrator has been designed specifically for the study of Multivibrator in As table and Monostable Modes using The board is absolute with an in-built supply and pulse generator. The Astable Multivibrator, often called as the Free-Running Multivibrator, is frequently used as a simple mean of generating square and rectangular wave signal. It has a non-stable state. The Monostable Multivibrator often called as One-Shot Multivibrator and is useful for generating a single pulse of desired duration in response to an external trigger.
FEATURES:-
- In-built +5V regulated DC Power Supply
- In-built 1KHz pulse generator for triggering themonostable circuit
- Good quality, reliable sockets and test points areprovided
- Strongly supported by systematic operatinginstructions
- A low cost training solution
SCOPE OF LEARNING:-
- To study the as a Monostable (One-Shot)Multivibrator
- To study the as an Astable (Free-Running)Multivibrator
TECHNICAL SPECIFICATIONS:-
- Operation on + 5 to + 18 V supply voltage in both as table and monostable modes
- Adjustable duty cycle.
- Timing from sec to hours.
- High current output.
- Capacity to source or sink current ‘of 200 mA
- Output can drive TIL.
- Temperature stability of 50 parts per million (ppm) per °C change in temperature or 0.005% per °C – Reliable, easy to use, and low cost.
- Mains Supply : 230V ±10%, 50Hz
- DC Bias Voltage : +5V
- Frequency of Trigger : 1KHz
- Pulse Generator
- Frequency Range : 600Hz – 3.2KHz (approximate)of Astable Multivibrator
- Frequency Range : 350Hz – 1KHz (approximate)of Bitable Multivibrator
- Output Voltage : 5V (approximate)
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
