ENCODER AND DECODER TRAINER
Encoder and Decoder Trainer: MTBE-44
Encoder and Decoder Trainer have been designed specifically for the study of 8-to-3 Line Encoder and 3- to-8 Line Decoder. The Training board explains the phenomena which encodes 8 data lines to 3 lines and decodes 3 data lines to 8 lines. The board is absolutely self-contained and requires no other apparatus.
FEATURES:-
- +5V SMPS Adaptor provided with the trainer for power supply
- Easy illustration of Encoder and Decoder
- LEDs for visual indication of inputs and outputs status
- SPDT switches for logic selection
- Good quality, reliable sockets are provided at appropriate
- places on board for connections
- Strongly supported by systematic operating instructions
- A low cost training system
SCOPE OF LEARNING:-
- Study and verification of the Truth Table of 8-to-3 Line Encoder.
- Study and verification of the Truth Table of 3-to-8 Line Decoder.
TECHNICAL SPECIFICATIONS:-
- Input : +5V DC
- Logic levels
- +5V : HIGH (Logic 1)
- 0V : LOW (Logic 0)
- LED Indication : LED will be ON (glow) for 1 state and will be OFF for 0 state
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
