Counters Trainer: MTBE-45
Counters Trainer is a compact, ready to use digital electronics experiment board. It helps students to get a practical insight into the working of the counters. Counters are undoubtedly the most important part of any digital circuit. Various applications of Counters include counting events or time periods, dividing frequency, addressing and serving as memory units. Counters trainer has a built in clock source, logic high-low input facility, LEDs for visual indication of input-output states. Besides this, a +5V DC adaptor is also provided for power supply.
FEATURES:-
- Stand Alone system
- Easy illustration of different types of counters
- LEDs for visual indication of input and output logic states
- SPDT switches for input logic selection
SCOPE OF LEARNING:-
- Study of 4 bit synchronous binary up Counter
- Study of 4 bit asynchronous binary up/down Counter
- Verification of operation of programmable Counter
TECHNICAL SPECIFICATIONS:-
- DC Power Supply : +5V DC
- Logic levels
- +5V : High (Logic 1)
- 0V : Low (Logic 0)
- LED Indication : LED will be ON for logic high or ‘1’ state and will be OFF for logic low or ‘0’ state
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
