SAMPLING OUTFITS AUGERS
Sampling Outfits Augers: MTST-28
Undisturbed samples of soil at different depths can be collected using these sampling tubes. The kit includes all necessary implements for boring, collection and sealing with wax. The operation may be carried out either using a tripod stand or without it. The equipment is supplied in a canvas carrying bag.
Features:-
- Sampling Outfits Augers
- Sampling Auger, Screw type with one meter long extension rod, Tee piece handle.
Technical Specification:-
- The outfit comprises: Sample Extractor, Screw type with a wire sample Timer.
- Split Mould, 38 mm dia x 76 mm long.
- Split mould, 38 mm inch dia x 88 mm inch long (in two parts) can be fitted to the screw type extractor enabling salt specimens to be prepared ready for unconfined compression test.
- They are fitted with quick release system.
- Sampling tube 38 mm dia x 150 mm long. Sampling Tube 38 mm dia x 200 mm long.
- Jarring link for driving the Sampling Tube.
- Adaptor with locking screw for fitting the sampling tube to jarring link.
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
