DYNAMIC CONE PENETRATION APPARATUS

Dynamic Cone Penetration Apparatus: MTST-09

The Dynamic Cone Penetrometer is a long steel rod with a standard size hardened steel cone at the penetrating end. Its length is approximately two meters, but it can be extended by extension rods. At upper end of the steel bar is a captive weight surrounding the rod, this weight is able to fall freely through a given drop height to achieve a standard amount of penetrative effort at every drop. By measuring the penetration of the cone against number of drops of the weight it is possible to plot resistance to penetration and indirectly the strength / compaction of the layer being tested. This equipment is very useful for testing fill compaction, especially in trench reinstatement, performed with care.

A typical test takes only a few minutes and therefore the instrument provides a very efficient method of obtaining information which would normally require the digging of test pits.Correlations have been established between measurements with the DCP and conventional in-situ CBR so that results can be interpreted and compared with CBR specifications for pavement design. A typical test takes only a few minutes and therefore the instrument provides a very efficient method of obtaining information which would normally require the digging of test pits.

Features:-

60° cone
8kg weight
575mm drop height
Testing depth to 850mm
Extension rods available for depths up to 2m
Portable and easy to operate
Tests can be carried out in minutes
Results correlate well with conventional CBR readings
Supplied in sturdy plastic carrying case
Well proven, robust design
Portable and easy to operate
Tests can be carried out in minutes
Results correlate well with conventional CBR readings
Detects layer boundaries and thicknesses
Ideal in locations where access is difficult (such as coal holes)

Category: Soil Testing Equipments

Description
Product Enquiry

Description

Technical Specification:-

Consists of one cone, plain 50 mm base dia and cone angle 60°, one cone adaptor, guide pipe assembly with one end cap and one driving head with threads for ‘A’ rod coupling
Tripod stand 6 meter height with built in ladder with pulley arrangements.
Drive fitted with chain.

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
