Description
Technical Specification:-
- Max. Vacuum -650 mm Hg = 85.5 kPa = 110 torr
- Motor Rotation 1450 r.p.m.
- Max. Power Consumption 60 W
- Horse Power 1 / 8 Hp
- Power 220 – 240 V, 50 / 60 Hz
- Oil Capacity 200 ml
- Intake Fitting ¼ Flare
- Stages 2
- High vacuum consist of a metallic casing having Cylindrical bore accommodating an eccentrically mounted slotted rotor bearing
- A pair of Vanes in the slots forced a part and pressed against the wall of the casing of the spring.
- The rotor these vanes slide along the wall Casing wiping before them the air which has entered the apparatus via the suction orifice.
- The air is finally forced out of the pump by the Vanes through the oil immersed exhaust valve.
- The pumps are made in either single or double stages, the pumps are electrically operated.
- V belts driven and mounted on iron base plates.
- The pumps are made in either single or double stages, the pumps are electrically operated.
- V belts driven and mounted on iron base plates.
Accessories:-
- O ring seal
- Removable top
- Spring
- Connection to system
- Connection to pump
- Activated alumina in basket
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK “keeps the right to modify the content in the product without prior notice.
