- Consists of a moving carriage
- Large water filled tank
- Fitted with a thermostatically controlled heater
- Testing range: 1.5m and 2m
- The apparatus consists of a Water bath with a thermostatic heater, and a circulating pump to maintain uniform water temperature.
- One half of the briquette moulds is fixed on a fixed plate in the water bath, the other half of the briquette mould is fixed to a carrier which slides over a rotating threaded shaft with a clutch.
- The motor and gears to rotate the shaft are housed in a cabinet fixed above the other end of the bath.
- A pointer fixed to the carrier moves over a scale graduated from 0-110 cm x 1mm fixed on the bath with “0” (zero) of the scale towards the fixed plate side.
- The rotating shaft has 2 speeds of travel for the bracket, 5cm/min and 1 cm/min., selected by a clutch.
- Water bath inside is aluminum, it is an insulated water bath.
- Water bath is provided with a drain. A heater with thermostatic control is fixed inside the water bath.
- Control switches for motor, stirrer, heater and indicator lamps are fixed at a convenient place on the water bath, complete with three briquette moulds and one base plate, all made of brass.
- Briquette mould
- Ductility Testing Machine with Cooling Unit
