Pendulum Impact Tester

Pendulum Impact Tester: MTAT -03

It is may be defined as the Versatile, extendable Pendulum Impact Tester with adjustable energy/velocity designed fornon-instrumented or instrumented tests according to charpy, IZOD or Impact Tensile Tests. This is easy to use impact tester is available in the energy.

Features:-

Easy sample mounting by pliers or by automatic sample centering Electric break that stops the pendulum on its highest position on the return swing for most productive testing.
Motorized pendulum return to the latched starting position.
4-digit digital display for direct absorbed energy reading Optional automatic hammer recognition.
Step-less adjustable energy/velocity allows CHARPY Izod or Impact Tensile Tests to be performed from 20%- 100% of energy range and impact velocity from 2.6 m/s to 5.5 m/s.
Safety guard with interlock so that the test cannot be started unless the guard is fully closed.
The guard can be fully opened for maintenance or cleaning.
Safety guard for operator
Compact and sophisticated design
Large dial and digital display
Electronic Measurement
Pneumatic specimen clamping
Horizontal adjustment system
Controlled by micro computer with LCD
Automatic statistics of testing data
Intelligent data sharing system
Customization available
Interchangeable strikers
Front guard provided for safety of operation
Separate strikers

Description

Technical Specification:-

Maximum Capacity
Minimum Scale Graduation
Impact Energy (Standard)
Pendulum Drop Angle: (140 Degree for charpy Test) & (90 Degree for IZOD Test)
Pendulum impact energy : 300J (charpy Test) & 168 J for Izod Test
Striking Velocity of Pendulum: 2.45 m/sec for charpy Test & 3.857 m/sec for Izod Test Min
Scale graduation: 2J
Max Permissible loss by friction etc.: 0 .50% of impact Energy

Accessories:-

Caliper gauge for checking V notch for Izod &CHARPY
Templates for checking 10 x 10 mm cross section of Izod / CHARPY test specimen.
Depth notch gauge including V & U notch gauges for checking depth below V/Unotch, angle and radius.
Izod support for 0.450″ dia Izod round specimen.
Self centering tong for quick and accurate setting of CHARPY test specimen.
‘V’ notch milling cutter
Impact Testing
