STABILITY CHAMBER
STABILITY CHAMBER : EQ-4S
Stability Chamber Microprocessor Control are microprocessor controlled chambers with soft touch keyboard for fast and accurate setting of various parameters. Just set the temperature, humidity & time and the system runs automatically. All the parameters are digitally displayed and reproducible.
Special Features:
- Temperature accurately controlled through microprocessor based controller.
- Automatic On / Off of the compressor according to need of process to reach & maintain the set values.
- Chamber illumination with fluorescent or ultra violet lights.
- Audio Visual alarm warning of temp. variation.
- User’s friendly Microprocessor Design/Operation.
Additional Features:
- Humidity accurately controlled through microprocessor controller in addition to temperature.
- Direct display of humidity in % RHQ. Audio visual alarm warning of low water levels & door opening.
- Humidity : 40% to 95% ± 3%.
Technical Data:
| Capacity | Temperature Range |
| 170 lit. / 6 cft. | 5°C to 60°C ± 1.0°C |
| 285 lit. / 10 cft. | 5°C to 60°C ± 1.0°C |
| 340 lit. /12 cft. | 5°C to 60°C ± 1.0°C |
| 170 lit. / 6 cft. | Ambient to 70°C ± 1.0°C |
| 285 lit. / 10 cft. | Ambient to 70°C ± 1.0°C |
| 340 lit./ 12 cft. | Ambient to 70°C ± 1.0°C |
Optional:
- Chart Recorder weekly.
- RS-232C interface available for humidity control through personal computer.
- Digital temp. indicator-cum-controller with computer data logger.
- Cyclic timer for regulating illumination conditions.
- Automatic Voltage Stabilizer 3KVA.
