INVERTED TISSUE RESEARCH CULTURE MICROSCOPES
INVERTED TISSUE RESEARCH CULTURE MICROSCOPES : JS-35
Inverted microscope is equipped with wide field eyepieces, long working distance plan achromatic objectives and very long working distance condenser and phase contrast unit. It can be observed transparent and unfinished living specimen in culture bottle or culture utensil. It is the ideal instrument suitable for research of living specimen structure, liquid, and deposits and so on. It also can be used in research institutes, universities, medical treatment, agriculture and animal husbandry, etc.
Features:
- Equipped with wide field eyepiece, long working distance plan achromatic objectives.
- Equipped with phase contrast unit, include very long working distance condenser, phase contrast objective and centering telescope.
- Coaxial coarse/fine focus system with tensional adjustable and up stop, minimum division of fine focusing: 2μm 6V-20W halogen lamp with brightness control.
Specifications:
- Body Type: All aluminum Body type.
- Eyepiece: Paired WF5X,10X, 15X
Objectives:
- LWD Plan Achromat Objective LPL10X/0.25
- LWD Plan Achromat Objective LPL25X/0.40
- LWD Plan Achromat Objective LPL40X/0.65
- LWD Plan Phase Contrast Objective LPL Ph+ 10X/0.25
- Condenser N.A.0.35 (W.D. 45/102mm
Head Type: Seidentopf Trinocular Head (Inclined 45°)
Mechanical Stage: Fixed Stage (With Clips)170mm×216mm
Filters: Filter (Blue) & Filter (Green)
Illumination: Halogen Lamp 6V/20W
