FLUID PROPERTIES & HYDRO STATICS BENCH

Fluid Properties & Hydro statics Bench: MTFM-07

The equipment is mounted on a steel-framed bench fitted with castors. A variety of measuring devices is incorporated either fastened to the back of the bench or free-standing. Water is stored in a polythene tank situated on the lower shelf of the bench.

The water can be transferred by two positive displacement hand pumps either to an elevated open storage tank connected to a number of glass tubes for free surface studies or to a plastic sink recessed into the working surface so that bench top experiments may be conducted without spillage. All excess water is returned to the storage tank via the sink drain.

Description

DEMONSTRATION CAPABILITIES:-

Determining the density specific gravity and viscosity of different liquids
Observing the effects of capillarity
Demonstrating that the free surface of a static liquid is horizontal
Studying the effect of flow on a free surface
Measuring changes in liquid level
Studying the relationship between intensity of liquid pressure and depths
Determining the position of the centre of pressure on a plane surface
Using a direct reading mercury barometer
Measuring air and water pressure using manometers
Comparing results obtained from various devices
Calibrating a Bourdon-type pressure gauge using a deadweight pressure gauge calibrator
Verifying Archimedes’ principle
Determining met centric height

TECHNICAL SPECIFICATIONS:-

Universal hydrometer: Range 0.70-2.00 subdivided in 0.01 intervals
Falling sphere viscometer: 40mm tube diameter
Hydrostatic pressure apparatus: Comprises counterbalanced precision quadrant
pivoted on knife edges at its centre of arc
Direct reading barometer: With compensated silvered metal scale
Range 585-790mm subdivided in 1mm intervals
Includes thermometer 100mm dial pressure gauge: Range 0-200 kN/m2(kPa) and equivalent head of water in meters
Deadweight pressure gauge calibrator: With 2 x 0.5kg, 1kg and 2.5kg weights
Lever balance: 178mm diameter pan, hook for use in buoyancy experiments, ant parallax cursor, double scale 0-0.25kg and 0-1.00kg
Thermometer: Range -10˚C to +50˚C

** Note: The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
