Description
VISUALISATION CAPABILITIES:-
- Reproducing the classic experiments conducted by Professor Osborne
- Reynolds concerning fluid flow condition
- Observing the laminar, transitional, turbulent flow and velocity profile
TECHNICAL SPECIFICATIONS:-
- Vertical test section fed from header tank with stilling media
- Bell mouth entry to promote smooth flow into the test section
- Dye injection system enables flow visualization
- Quick release fitting for easy connection to Hydraulics Bench
- Educational software available as an option
- Test pipe diameter: 10.0 mm
- Length of test pipe: 700 mm
- Dye reservoir capacity: 0.45 l
