Understanding Network Theorems: MTEE-46
Understanding Network Theorems is a compact, ready to use experiment board and has been designed specifically for the study & verification of network theorems in DC circuits.
In network analysis, the fundamental rules are ohm’s law and Kirchhoff’s laws. These laws may be applied to analyze any circuit configuration but for solving complex circuits, use of “Network theorems” is much better because it simplifies the analysis of complicated circuits.
It is a useful product for students to study and verify Norton’s, THEVENIN’S, Maximum Power Transfer, Superposition, and Reciprocity & TELLEGEN’S Theorems. This product explains corresponding theorems in very easy way, TELLEGEN’S theorem is explained in individual block and Norton’s, THEVENIN’S& Maximum Power Transfer
Theorems are explained in a single circuit so that student can compare these theorems with each other.
Superposition and Reciprocity theorems are also explained in a single circuit. The product is designed and presented in such a way that student can easily measure all the electrical parameters like voltage, current and resistance.
FEATURES:-
- Exclusive and compact design
- In-built power supply
- Constant current source
- On board Voltmeter & Ammeter
- Straight forward representation of all theorems
- On board equivalent circuits
- Potentiometer is provided to vary load resistance
- Learning material CD.
TECHNICAL SPECIFICATIONS:-
- Mains power supply : 90 – 270V ±10%, 50Hz
- DC power supply : +5V, Regulated
- +12V, Regulated
- Constant Current Source : 3.2 mA
- Voltmeter Range : 200mV to 20V
- Ammeter Range : 200µA to 200Ma.
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
