POWER FACTOR DEMONSTRATOR
Power Factor Demonstrator: MTEE-27
Power Factor Demonstrator is a unique product that to demonstrate the significance of Power Factor in an electrical circuit and explain basic concept and importance of Real Power, Apparent power, Reactive Power.
It contains various values of Resistor, Capacitor, and Inductor inbuilt in the product. Student can make different circuit using different combination of Resistor, Capacitor, and Inductor and analysis of power factor.
Students can also get to know the phenomenon of lagging and leading between current and voltage for different R, L, and C combination circuit. Product includes facility to display Voltage, Current Power and Power Factor on a single LCD display makes this product unique. This product can also interface with Oscilloscope. Students to analysis phase between voltage and current.
FEATURES:-
- Alphanumeric 16 x 2 Big Font LCD for better visibility
- Inbuilt BNC terminals to observe V and I simultaneously
- Equipped with inbuilt R, L and C load required for experiment
- Microcontroller based Measurement unit with high accuracy and resolution
- Designed by considering all the safety standards
- Diagrammatic representation for the ease of connections
TECHNICAL SPECIFICATIONS:-
- Mains supply : 230V ±10%, 50Hz
- Primary Voltage : 0- 230V AC
- Secondary Voltage : 0- 115V AC
- Current Rating : 150mA
- Primary Voltage : 0- 230V AC
- Secondary Voltage : 0- 9V, 15-0-15V AC
- Current Rating : 300mA
- Resistance : 500O, 400W200O, 400W
- Capacitor : 12.5µF 440/450V20µF 440/450V
- Inductor : 200mH, 1A
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
