DATA ACQUISITION SYSTEM WITH SD CARD
Data Acquisition System with SD card: MTDA-03
DAQ device endowed with true high quality measurement, its ability of logging data in micro SD Card makes it favorable for user to examine intimately all the measurement using our PC software at any time. This device comes with 4 GB micro SD card which is having storage facility of logging data up to 2 year. For easy connections, screw terminals are provided. It also incorporated real time display functionality over LCD and 7 Segment intended for easy view.
FEATURES:-
- 8 Single ended analog inputs
- Up to 76.9KSPS speed
- Built in signal conditioning
- Micro SD card (4GB) storage capacity
- Logging capacity of 2Year
- In-built RTC with CMOS battery backup
- LED and LCD display
- Can be interfaced with PC directly
- Graph view: Second/Minute/Hours/Day
- Auto insert data from SD card
- Globally availability of data or graph (through My SQL)
TECHNICAL SPECIFICATIONS:-
- Single ended analog input Channels : 8
- Input Voltage range : 0 to 2.5V
- RTC : Available
- Data accuracy : ±2LSB absolute
- Resolution : 10 bit
- Conversion Time : 13 – 260µs
- Speed : Up to 76.9KSPS (Up to
- 15KSPS at maximum
- resolution)
- Storage type : Micro SD card (4GB)
- Logging capacity : up to 2 Year
- Built-In signal conditioning : Available
- I/O Connector : 18- screw terminals
- Weight : 200gm (approx.)
- Power : 5V DC/200Ma
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
