EXPERIMENTATION WITH FUEL CELL
Experimentation with Fuel Cell: MTCN-02
Fuel Cell demonstrates the Chemistry and Physics principle present in Fuel cell technology. In this technology water is divided in to its basic components i.e. hydrogen and oxygen using the process of electrolysis when current is supplied from Sun light using Solar Panel. After splitting, these two gases are stored in two different tanks to make a fuel cell. When required these two gases are recombined to generate electricity using a reverse process of electrolysis.
FEATURES:-
- Complete Training System to study Solar – Hydrogen cycle
- Reversible Fuel Cell-both as an Electrolyze and as a Fuel Cell
- Measurement and Application modes
- Weather proof Solar Panel
- Portable and light weight
TECHNICAL SPECIFICATIONS:-
- Solar Panel
- Voltage (at optimum power point) : 2.2V DC
- Current (at maximum power point) : 450mA
- Electrolyze Function
- Input Voltage : 1.8~2.6V DC
- Input Current : 0.7A
- Hydrogen Production Rate : 7ml / min at 1A
- Oxygen Production Rate : 3.5ml / min at 1A
- Fuel Cell Function
- Output Voltage : 0.9V DC
- Output Current : 360mA
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
