DIGITAL THEODOLITE

Digital Theodolite: MTSE-02

It may be defined as the theodolite is a useful tool by the surveys the instrument is capable of finding both vertical angles and horizontal angles when is combined with technical studies also can determinate horizontal distances and a differentiation elevation.

Next the survey team takes out the theodolite of its case and adapts it over the tripod with the screw and then elevates the theodolite up to survey eye.
The theodolite has to stay exactly over the mark of the floor this can be theodolite and stays on the point.
Theodolite setup: – in this section we learn how to unpack, setup, center and level the theodolite.

Features:-

Eyepiece of telescope
Telescope focusing knob
Objective lens
Vertical clamp screw
Vertical tangent screw
Power switch
Base plate
Leveling screw
Easy to operate
Optimum performance
Long functional life
Circular vial
Port for controller
Eyepiece for optical plummet
Focusing knob for centering
Plate level
Carrying handle
Detection of 0° position is no longer needed. Stable, high-accuracy measurement.
The laser pointer is injected in collimation direction by simply operating one switch. Workers can perform work without guidance by observation personnel.

Category: Survey Equipments

Description
Product Enquiry

Description

Technical Specification:-

Method incremental grating disk
Accuracy 5″
Mindreading1″/5″/10″
Tilt sensor provided
Compensating range 3
Level parameter
- Circular level 8″/2mm
- Plate level 30/2mm

Telescope: –

Magnification 30
Image erect
Field of view 1/30 (2.6%)
Min. focus 1.3m
Optical aperture 45mm
Length of sleeve 155mm
Resolving power 2.5″
Stadia ration 100
Stadia content 0
Storage temperature -40 +60
Operating temperature -20 +50

Accessories:-

Mainframe
Rechargeable battery
Battery charger
Operation manual
Carrying case
Belt for case
Plummet
Tools kit

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
