UNCONFINED COMPRESSION TEST MACHINE
Unconfined Compression Test Machine: MTST-37
Spring type unconfined compression testing apparatus can be used either in a laboratory or in field. This apparatus is as per the design of Building Research Station, U. K. Unconfined Compression Test Apparatus (Spring Type – Autographic)
Hand Operated: Proving ring type Comprises of a hand operated load frame, cap. 30KN (3000 kgf.) screw jack for loading, handle and strain dial gauge bracket, adaptor for proving ring, conical seats and male/female coning tools for 38 mm dial samples. Supplied without proving ring and dial gauge.
Motorized Cum Hand Operated: Comprises a screw operated load frame capacity 50 KN (5000 kgf.) with a gear box and motor drive giving 1.25, 1.5 and 2.5mm/min, rates of strain, pair of cone seating, adaptor for proving ring and strain dial gauge bracket supplied with one pair of male/female coning tools for 38 mm dia samples but without proving ring and dial gauge. Suitable for operating on 230 volts, single phase AC Supply.
Technical Specification:-
- Consists of a spring operated load frame with arrangements for loading 38 mm x 76 mm samples, one set of four load springs of stiffness 0.2 kg, 0.4 kg, 0.8 kg, and 1.6 kg/mm, a calibrated mask and one set of 50 charts, in a metal carrying case.
- Capacity 5000 kg
- Motor drive 1.25, 1.5, 2.5mm/min.
- Power Supply 230 V, Single Phase A.C.
Accessories:-
- Coning tools in pairs
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
