INFRARED MOISTURE BALANCE

Infrared Moisture Balance: MTST-15

It is a fast, accurate method to derive direct moisture % in a sample by Loss on Heating Method. Heating arrangement consists of a 250 watt heating lamp with a solid state power stat to control rate of drying and also temperature. This is very reliable and sturdy instrument for an accurate determination of the moisture content of materials which do not undergo chemical change when exposed to infra red radiations. The instrument is especially useful for the substance which quickly reabsorbs moisture after drying. Observations can be taken quickly and the results obtained are accurate. The instrument can be used for reliable determination of moisture content of agricultural soil, foods, chemicals, plastics, Pharmaceuticals, construction soils and other similar materials.

Features:-

250 Watts Infrared Lamp
Fully Automatic Temperature Control with Timer
Alternate Choice of Variac or Dimmer
Direct Moisture Reading
Rugged and Durable
Easy to use and maintain

Optional Fittings:-

The instrument can be supplied with Digital timer with alarm.
This timer gives a continuous buzz after turning the infrared lamp off after specified time.
Sophisticated and accurate
Digital Moisture Balance.

Description

Technical Specification:-

The instrument consists of a 250 watt infrared lamp, a sensitive torsion balance and a temp.
Accuracy (%) +/- 1%
Operating Temperature (Degree Celsius) 0-50 Degree Celsius
Acceptable Sample 5 gms, 10 gms or 25 gms
Scale Range 0- 100%
Accuracy 0.2%
Heater 250 Watts IR Lamp
Temperature Control Digital Temperature Controller with Timer Variac or Solid State Dimmer
Temperature Control Accuracy +-1C
Voltage 230V, 50Hz
Control, all housed in a compact cabinet made of Aluminum, having robust design.
The Infra Red radiation from the lamp is used for heating the sample.
The temp is controlled by the solid state control.
The sensitive torsion balance used magnetic damping to damp the vibrations of the pan.
The instrument is directly calibrated in percentage of moisture between 0 to 100%.
The Aluminum pans are cheap and disposable.
This helps avoid loss of time which otherwise would be spent each time to clean the pans after the experiment is done.
Complete with instruction manual.
It is available in following Capacities to suit individual requirements.
- Capacity 5g (Approx.): For applications in pharmaceuticals, light powders, chemicals, detergent.
- Capacity 10g (Approx): For grains, rice, relatively heavy grained products MTC.
- Capacity 25 g (Approx.) For Coal, Cashew nuts, Sand, Agricultural Soil MTC.

Accessories:-

Disposable Pans
Sample Pan
Retainer Pan
Torsion Wire
Heating Lamps

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
