VIBRATING MACHINE

Vibrating Machine: MTCT-21

Vibrating machine is used for the preparing of mortar cubes for the determination of compression strength of ordinary and rapid hardened Portland cement, low heat Portland cement, Portland blast furnace cement and high alumina cements.

Features:-

Low noise
Compact design
Easy movement
Stable operation
Light Weight
Good mechanical performance
All copper coil, aluminum of enclosure

Description

Technical Specification:-

2x150w Ac motors
Fiber Glass Frame
Frequency setting 30,35,40,45Hz
Time Setting 30s,60s,90s,300s
Amplitude High and Low
Handlebar Cover HDR or Dipping
Remote Control/Transportation Wheels/Exercise Mat can be attached
Foot Print L700xW700xH1340mm
Plate Useable Scope:600x435mm
The complete frame assembly consists of a vice to hold a 7.06cm cube mould and two studs threaded at top and a hopper to feed the sample in the mould
This assembly is supported on four springs and has an in built rotating shaft which rotates eccentrically and thus imparts vibrations to the entire frame
A balance weight is an integral bottom part of the frame
The centre of gravity of the assembly is brought to the centre of the eccentric shaft or within a distance of 25mm below it
The electric motor drives the shaft of the frame and thus imparts required vibrations to the mould.
The frequency of vibration is 12000+/-400 vibration per minute
Supplied complete with on 7.06cm cube mould with loose base plate, a time switch 0-5mins x 1min and certificate of vibration from a standard laboratory
Spares : Set of Springs, Belt and Belt guard
The machine consists of a vibrating frame assembly and an electric motor mounted on a sturdy base
