Distillation For Cut black Bitumen

Distillation For Cut black Bitumen: MTBA -11

It may be defined as the amount of the more volatile constituents in cut-back asphaltic products is measured. The properties of the residue after distillation are not necessarily characteristic of the bitumen used in the original mixture or of the residue which may be left at any particular time after application of the cut-back asphaltic product. The presence of silicone in the cut-back may affect the distillation residue by retarding the loss of volatile material after the residue has been poured into the residue container.

Features:-

Thermometer
Cork stopper
Window
Shield
Flask
Two sheets wire gauge
Chimney
Burner
Stand
Water jacketed condenser
Tight ground glass or cork joints
Blotting paper
Receiver

Description

Technical Specification:-

Distillation Flask, 500 ml side-arm
Condenser, standard glass-jacketed, of nominal jacket length from 200 to 300 mm and overall tube length of 450 ± 10 mm
Adapter, heavy-wall (1 mm) glass, with reinforced top, having an angle of approximately 1050
The inside diameter at the large end shall be approximately 18 mm, and at the small end not less than 5 mm.
The lower surface of the Adapter shall be on a smooth descending curve from the larger end to the smaller
The inside line of the outlet end shall be vertical, and the outlet shall be cut or ground (not fire-polished) at an angle of 45 ± 5 deg to the inside line Shield, 22 gauge sheet metal, line with 3-mm asbestos or high temperature light weight flexible ceramic insulation, and fitted with suitable transparent heat resistant non-discoloring windows, of the form and dimensions.

Accessories:-

low distillation thermometer range -2°C to +300°C
low distillation thermometer range -2°C to +400°C
