Automatic Marshall Compactor

Automatic Marshall Compactor: MTBA-01

The Marshall Compactor – Automatic CRT-MARSH-HR automatically compacts the samples of asphalt mixture and stops after a pre-determined number of blows. Moulds are held in position by an easy to use clamping mechanism. The hammer release mechanism is designed to give an accurate and repeatable hammer drop height. It is also easily adjustable. To ensure operator safety, moving parts are protected by the safety guard and the machine operation is prevented when mould is unclamped.

Features:-

Automatic control
Digital controller for precise operation
Robust mechanism to lift weight and unclamp mould
Uses steel and bronze in place of plastic wear parts
Quick release hammer foot
An accurate non-contact counter to avoid part wear
Drop height can be accurately adjusted in 1mm increments
Electronic components meet SIL level 2
Machine calibrated with traceable equipment
Noise reduction cabinet available on request
Option for mould extraction accessory
Compaction of asphaltic paving material to a target mixture density or void content
Assessment of mixture compatibility
Preparation of cylindrical test specimens
Automatic control and a reliable rammer lifting device

Category: Bitumen and Asphalt Testing Equipment

Description
Product Enquiry

Description

Technical Specification:-

Speed Normally 50 impacts in 55-60 seconds
Electrical Supply 220-240 Volts 50Hz @ 13A
Working space
Falling Height 457 ± 5mm
Hammer Weight 4535 ± 15 g
Tamping Face Dia. 98,5 mm
Concrete Base Dimension 450x450x200 mm
Laminated Hard work Block Dimensions 200x200x450 mm
Blows Frequency 50 blows in 55 s to 60 s
Equipped with safety guard

Note:-Accessories are not included in the price of main device (unless stated otherwise) and may be purchased separately if required.

Accessories:-

Specimen extruder
Mould

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK “keeps the right to modify the content in the product without prior notice.
