VERTICAL ELECTROPHORESIS APPARATUS
VERTICAL ELECTROPHORESIS APPARATUS : EM-41
It is required in Biotechnology, Molecular Biology applications in colleges, Universities, Research Institutes.
It is meant for protein characterization.
The unit is jointless, moulded of transparent Polycarbonate to avoid leakage. The unit is based on Acrylic sheet fitted with 3 levelling screws. Complete with Acrylic cover.
- Dimentions (Outer) (L*W*H) 15x18x15mm
- Gel Size (cm) 8×7 (1Gel)
- Buffer Required (ml) 100 + 150
- Platinum Electrodes 2 Nos.
Supply Complete with standard accessories :
- Wires
- Glass plate-1 and 1 notched rectangular Total 2nos.
- One set spacers of 1.0mm, 1.5mm – 4 pcs. each
- 4 sets of Nylon moulded combs of 7 wells & 10 wells in 0.1mm and 1.5mm thickness.
- Silicon Gasket – 1 No
