System is equipped with 4 line alphanumeric LCD display with backlit and 19 soft touch membrane type keys that provides a convenient interface for entering the data. Independent stirrer and platform keys on the front panel allow the user to easily start/stop stirrer movement or displacement of platform in the required direction at any time.
The instrument has the storage facility for 200 samples. The samples being analyzed are automatically stored in the memory in different batch and sample numbers. The system has three programming modes i.e. Routine, Sustain and Control mode. It has the facility for setting up 20 different test methods using Routine and Sustain modes which are retained in the memory even when the power is switched OFF. Provision has also been made for attachment of any dot matrix printer with centronics interface so that any of the stored setups/results can be printed.
The unit is provided with dissolution vessel with cover, having necessary arrangement to hold temperature sensor and the same is placed in the sturdy, acrylic water bath. The large spread out stainless steel heater ensures perfectly uniform heating. The instrument has dual channel temperature system with sensors to monitor the test temperature of dissolution vessel as well as that of the water bath.
The motorized platform’s (stirrer unit) up/down movement of the instrument improves the accessibility for sampling. Stirrer speed is accurately controlled and maintained at +1 rpm by microcontroller as per IP, USP specifications.
The elapsed time for the current ongoing test is retained in the instruments memory. In case of power failure during the run mode, when the instrument is switched On again, the user has the option to run the test from the point of the power failure.
|LED’||6 LED’s, (3 LED’s for Test status like Run, Alarm, End and 2 LED’s for Platform up/down status and one for heater ON/OFF status.)|
|Prog. Mode||(Routine, Sustain and Control mode )Facility for 20 different test setups.|
|Printer||Provision for the attachment of dot-matrix printer.|
|Setup Data||Facility for 20 different test setups available|
|Printer||Provision for the attachment of dot-matrix printer|
|Stirrer||Speed 25 – 200 RPM, ± 1 RPM|
|Accuracy||± 1 RPM|
|Temperature||Range 30 – 50°C|
|Temp. Control||Microprocessor Based using PT100/Semiconductor Sensor|
|Sampling||Reaction Vessel 1000 ml jars with stirrer pedals and baskets|
|Power||230 V ± 10%, 50 Hz. AC|
