SERIES/PARALLEL PUMPS
Series/Parallel Pumps: MTFM-30
This accessory comprises a fixed-speed pump assembly and independent discharge manifold interconnected by flexible tubing with quick-release connectors.
This auxiliary pump is intended to be used in conjunction with the basic Hydraulics Bench. The auxiliary pump is mounted on a support plinth which stands adjacent to the Hydraulics Bench primary pump.
MEASUREMENT CAPABILITIES:-
- A single centrifugal pump at a single speed
- Two similar pumps operating in a parallel configuration at the same speed
- Two similar pumps operating in a series configuration at the same spee
TECHNICAL SPECIFICATIONS:-
- Fixed-speed pump with similar performance characteristics to pump in Hydraulics Bench
- Mounted on floor-standing plinth with on/off switch
- Discharge manifold with flow control valve and pressure gauges
- All hoses and fittings supplied for easy connection to Hydraulics Bench in either series or parallel configuration
- Educational software available as an option
- Pump : Centrifugal type
- Max head : 21 m H2O
- Max flow : 35 l/s
- Motor rating : 36 kW
- Pressure gauge range : 0-60 m H2O
- Compound gauge range : -10 to +32 m H2O
** Note: The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
